Stainless Steel Seamless Pipes and Tubes

  • Home
  • /
  • Pipes and Tubes
  • /
  • Stainless Steel Seamless Pipes and Tubes

Stainless Steel Seamless Pipes and Tubes are manufactured using high-quality stainless steel materials. These products come in various grades, with Grade 304 being the most commonly used due to its cost-effectiveness and reliable performance. Natron Steel is a leading supplier, stockist and dealer of Stainless Steel Pipes and Tubes in India, providing products that meet international quality standards.

ASTM A312 Stainless Steel Seamless Pipe, ASTM A312m Seamless Tube Weight Chart, Stainless Steel 304 Seamless Pipe, Stainless Steel 316 Seamless Pipe at best Price in India

Our pipes are available in a range of dimensions as per ASTM, ASME, and API standards, including specifications like ASTM A213, A249, and A269. We offer both welded and seamless pipes, with seamless pipes being more dimensionally accurate. The pipes range in nominal bore sizes from 1/8 inches to 30 inches, with outer diameters ranging from 0.35mm to 6.35 inches, and wall thicknesses ranging from 0.1mm to 1.2mm.


ASTM A312 SMLS Pipes and Tubes Specification

Range  6NB to 1200NB
Outer Diameter  1/8" NPS to 12" NPS
Thickness  0.6 mm to 12.7 mm
Schedules  SCH. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS.
Length  Single Random, Double Random & Cut Length
Specifications  ASTM A312 / ASTM SA312
Types  Round, Square, Rectangle, Hydraulic, Honed Tubes
End  Plain End, Beveled End
Product Name Executive Standard Dimension Steel Code / Steel Grade
Seamless Austenitic Stainless Steel Pipes ASTM A312/A312M, ASME SA312/SA312M OD: 1/4"~20"
WT: SCH5S~SCH80S		 TP304, TP304L, TP304H, TP310, TP310S, TP316, TP316L, TP316Ti, TP317, TP317L, TP321, TP321H, TP347, TP347H
Seamless Austenitic Stainless Steel Tubing for General Service ASTM A269, ASME SA269 OD: 6.0~50.8mm
WT: 0.8~10.0mm		 TP304, TP304L, TP304H, TP310, TP310S, TP316, TP316L, TP316Ti, TP317, TP317L, TP321, TP321H, TP347, TP347H
Seamless Austenitic Alloy-Steel Boiler, Super Heater and Heat-Exchanger Tubes ASTM A213/A213M, ASME SA213/SA213M OD: 6.0~50.8mm
WT: 0.8~10.0mm		 TP304, TP304L, TP304H, TP310, TP310S, TP316, TP316L, TP316Ti, TP317, TP317L, TP321, TP321H, TP347, TP347H
Seamless Duplex Stainless Steel Tubing for General Service ASTM A789 / A789M OD: 19.0~60.5mm
WT: 1.2~5.0mm		 S31803, S32205, S32750
Seamless Duplex Stainless Steel Pipes ASTM A790 / A790M OD: 3/4"~10"
WT: SCH5S~SCH80S		 S31803, S32205, S32750
Seamless Stainless Steel Mechanical Tubing ASTM A511 OD: 6.0~50.8mm
WT: 1.8~10.0mm		 MT304, MT304L, MT304H, MT310, MT310S, MT316, MT316L, MT317, MT317L, MT321, MT321H, MT347
Seamless Stainless Steel Tubes for Pressure Purposes EN 10216, DIN 17456, 17458 OD: 6.0~530.0mm
WT: 0.8~34.0mm		 1.4301, 1.4307, 1.4541, 1.4401, 1.4404, 1.4571, 1.4878, 1.4432, 1.4462

Natron Steel’s Stainless Steel Tubes are used in a variety of applications, including corrosive environments, industrial processes, commercial installations, and marine applications. Different grades of stainless steel provide varying physical and mechanical properties, allowing our products to meet the specific requirements of each industry. The ASTM A312 Pipes and other specifications are suitable for pressure vessels and high-temperature environments.


For more information about our ASTM A312 Stainless Steel Tubing and pricing, please contact us today. Natron Steel is dedicated to providing high-quality solutions for all your seamless pipe and tube needs.

SS Seamless Pipe and Tube Weight Per Foot

NPS Outside Diameter Wall Thickness Weight Weight
in mm in mm Sched kg/Mtr Lb/ft
1/2″ 0.840 21 0.109 2.769 40 STD 1.268 0.851
0.147 3.734 80 STD 1.621 1.088
3/4″ 1.050 27 0.113 2.870 40 STD 1.684 1.131
0.154 3.912 80 STD 2.195 1.474
1″ 1.315 33 0.133 3.378 40 STD 2.501 1.679
0.179 4.547 80 STD 3.325 2.172
1 1/4″ 1.660 42 0.140 3.556 40 STD 3.385 2.273
0.191 4.851 80 STD 4.464 2.997
1 1/2″ 1.900 48 0.145 3.683 40 STD 4.048 2.718
0.200 5.080 80 STD 5.409 3.361
2″ 2.375 60 0.154 3.912 40 STD 5.441 3.653
0.218 5.537 80 STD 7.480 5.022
2 1/2″ 2.875 73 0.203 5.516 40 STD 8.629 5.793
0.276 7.010 80 STD 11.411 7.661
3″ 3.500 89 0.216 5.486 40 STD 11.284 7.576
0.300 7.620 80 STD 15.272 10.253
4″ 4.500 114 0.237 6.020 16.073 10.790
0.337 8.560 22.318 14.983
6″ 6.625 168 0.188 4.775 19.252 12.924
0.203 5.516 20.739 13.923
0.219 5.563 22.318 14.983
0.250 6.350 25.354 17.021
0.280 7.112 40 STD 58.263 18.974
0.312 7.925 31.334 21.036
0.375 9.525 37.285 25.031
0.432 10.973 80 XHY 42.561 28.573
0.500 12.700 48.719 32.708
8″ 8.625 219 0.188 4.775 25.233 16.940
0.203 5.156 27.198 18.259
0.219 5.563 29.286 19.661
0.250 6.350 20 33.308 22.361
0.277 7.036 30 36.786 24.696
0.322 8.179 40 42.352 28.554
0.375 9.525 49.216 33.041
0.406 10.312 60 53.085 35.638
0.500 12.700 80 XHY 64.627 43.388
10″ 10.750 273 0.188 4.775 31.588 21.207
0.219 5.563 36.689 24.631
0.250 6.350 20 41.759 28.035
0.307 7.798 30 51.002 34.240
0.344 8.738 56.946 38.231
0.365 9.271 40 STD 63.301 40.483
0.438 11.125 71.852 48.238
0.500 12.700 60 XHY 81.530 54.735
0.594 15.088 80 95.969 64.429
12″ 12.750 324 0.188 4.775 37.570 25.222
0.219 5.563 43.657 29.309
0.250 6.350 49.713 33.375
0.281 7.137 55.739 37.420
0.312 7.925 61.735 41.445
0.375 9.525 73.824 49.562
0.406 10.312 79.727 53.525
0.500 12.700 97.438 65.415
0.562 14.275 108.966 73.154
14″ 14.000 356 0.188 4.775 41.308 27.732
0.219 5.563 48.012 32.233
0.250 6.350 20 54.685 36.713
0.281 7.137 61.327 41.172
0.312 7.925 67.939 45.611
0.375 9.525 STD 81.281 54.568
0.438 11.125 40 94.498 63.441
0.500 12.700 XHY 107.381 72.090
0.625 15.875 132.983 89.278
16” 16.000 406 0.188 4.775 47.290 21.748
0.219 5.563 54.980 36.910
0.250 6.350 10 62.639 42.053
0.281 7.137 70.268 47.174
0.312 7.925 20 77.866 52.275
0.344 8.738 85.677 57.519
0.375 9.525

30

STD

 93.213 62.578
0.438 11.125 108.433 72.797
0.500 12.700

40

XHY

 123.289 82.770
18″ 18.000 457 0.219 5.563 61.948 41.588
0.250 6.350 70.593 47.393
0.281 7.137 79.208 53.176
0.312 7.925 20 87.792 58.939
0.375 9.525 STD 105.144 70.588
0.438 11.125 30 122.369 82.152
0.500 12.700 XHY 139.198 93.450
0.562 14.275 40 155.904 104.666
0.625 15.875 172.754 115.978
20″ 20.000 508 0.250 6.350 78.547 52.733
0.282 7.163 88.458 59.386
0.312 7.925 97.719 65.604
0.375 9.525 20 STD 117.075 78.598
0.438 11.125 136.305 91.508
0.500 12.700 30 XHY 155.106 104.130
0.594 15.088 40 183.378 123.110
0.625 15.875 192.640 129.328
0.688 17.475 211.368 141.901
24″ 24.000 610 0.250 6.350 94.456 63.413
0.281 7.137 106.029 71.183
0.312 7.925 117.573 18.932
0.375 9.525 20 STD 140.938 64.618
0.438 11.125 164.176 110.219
0.500 12.700 XHY 186.923 125.490
0.625 15.875 232.410 156.028
0.688 17.475 40 255.148 171.293
0.750 19.050 277.401 186.233
30″ 30.000 762 0.250 6.350 118.318 79.433
0.281 7.137 132.851 89.189
0.312 7.925 10 147.353 98.925
0.375 9.525 STD 176.731 118.648
0.438 11.125 205.983 138.286
0.500 12.700 20 XHY 234.647 157.530
0.625 15.875 30 292.066 196.078
0.688 17.475 320.817 215.380
0.750 19.050 348.988 234.293
36″ 36.000 914 0.250 6.350 142.180 95.453
0.281 7.137 159.672 107.196
0.312 7.925 10 177.133 118.918
0.375 9.525 STD 215.525 142.678
0.438 11.125 247.790 166.353
0.500 12.700 20 XHY 282.372 198.570
0.625 15.875 351.723 236.128

0.688

 17.475 386.487 259.467

0.750

 19.050 420.576 282.353
42″ 42.000 1067 0.312 7.925 206.914 138.911
0.375 9.525 STD 248.319 166.708
0.500 12.700 XHY 33.097 221.610
0.750 19.050 492.163 330.413
48″ 48.000 1219 0.375 9.525 STD 284.112 190.738
0.438 11.125 331.404 222.487
0.500 12.700 XHY 377.822 253.650
0.750 19.050 563.750 378.473
0.875 22.225 655.969 440.383

SS Seamless Tube Chemical Properties

Grade UNS # Content % by weight
Carbon Manganese Phosphorus Sulfur Silicon Chromium Nickel Molybdenum
TP304 S30400 0.08 2.00 0.045 0.030 1.00 18 – 20 8 – 11 x
TP304L S30403 0.035 2.00 0.045 0.030 1.00 18 – 20 8 – 13 x
TP316 S31600 0.08 2.00 0.045 0.030 1.00 16 – 18 10 – 14 2 – 3
TP316L S31603 0.035 2.00 0.045 0.030 1.00 16 – 18 10 – 14 2 – 3

SS Seamless Pipe and Tube Sizes Chart in Inch

Wall Thickness SS Seamless Tube Sizes ( O.D.)
.010 1/16" , 1/8" , 3/16"
.020 1/16" , 1/8" , 3/16" , 1/4" , 5/16" , 3/8"
.012 1/8"
.016 1/8" , 3/16"
.028 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 3/4" , 1" , 1 1/2" , 2"
.035 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 7/16" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.049 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/8" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.065 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 3/4" , 2" , 2 1/2" , 3"
.083 1/4" , 3/8" , 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 7/8" , 2" , 2 1/2" ,3"
.095 1/2" , 5/8" , 1" , 1 1/4" , 1 1/2" , 2"
.109 1/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2"
.120 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 2" , 2 1/4" , 2 1/2" , 3"
.125 3/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 3 1/4"
.375 3 1/2"
SS Seamless Pipe and Tube Sizes Chart in Inch
1/8" IPS(.405"O. D.) 3 1/2" IPS( 4.000"O. D.)
SCH 40, 80 SCH 10, 40, 80, 160, XXH
1/4" IPS(.540"O. D.) 4" IPS(4.500"O. D.)
SCH 10, 40, 80 SCH 10, 40, 80, 160, XXH
3/8" IPS(.675"O. D.) 5" IPS( 5.563"O. D.)
SCH 10, 40, 80 SCH 10, 40, 80, 160, XXH
1/2" IPS(.840"O. D.) 6" IPS(6.625"O. D.)
SCH 5, 10, 40, 80, 160, XXH SCH 5, 10, 40, 80, 120, 160, XXH
3/4" IPS(1.050"O. D.) 8 ” IPS(8.625"O. D.)
SCH 10, 40, 80, 160, XXH SCH 5, 10, 40, 80, 120, 160, XXH
1" IPS:(1.315′O. D.) 10" IPS(10.750"O. D.)
SCH 5, 10, 40, 80, 160, XXH SCH 10, 20, 40, 80 (.500), TRUE 80(.500)
1-1/4" IPS(1.660"O. D.) 12" IPS(12.750"O. D.)
SCH 10, 40, 80, 160, XXH SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500)
1-1/2" IPS(1.900"O. D.) 14" IPS(14.000"O. D.)
SCH 10, 40, 80, 160, XXH SCH10 (.188), SCH40 (.375)
2" IPS(2.375"O. D.) 16" IPS(16.000"O. D.)
SCH 10, 40, 80, 160, XXH SCH10(.188), SCH40(.375)
2 1/2" IPS(2.875"O. D.) 18" IPS (18.000"O. D.)
SCH 10, 40, 80, 160, XXH SCH-40 (.375)
3" IPS( 3.500"O. D.)
SCH 5, 10, 40, 80, 160, XXH
Stock of Stainless Steel Seamless Pipes and Tubes
SS TP 304 Seamless Pipes and Tubes Stainless TP 304L Seamless Tubing
ASTM A213 Stainless Welded Pipe and Tubes A249 SS TP Welded Pipes and Tubes
ASTM A358 310S Stainless ERW Pipe and Tubes A312 SS 310 Rectangular Seamless Pipe
ASTM A213 316 SS Rectangular Tubes TP 316L SS ERW Pipes and Tubes
TP 316H Stainless Coiled Seamless Tubing SS Heat Ex-changer Tubes
Stainless 317L Round Pipe Tubing ASTM A213 317 Stainless Square Seamless Pipes
ASME TP Stainless Electric Fusion Welding Pipes TP 321 SS EFW Pipes and Tubes
